ENGLISH
La vitrine de diffusion des publications et contributions des chercheurs de l'ÉTS
RECHERCHER

Formation of precipitates in parallel arrays on LPSO structures during hot deformation of GZ41K magnesium alloy

Téléchargements

Téléchargements par mois depuis la dernière année

Plus de statistiques...

Saadati, Mohammad, Khosroshahi, Rasoul Azari, Ebrahimi, Gholamreza et Jahazi, Mohammad. 2017. « Formation of precipitates in parallel arrays on LPSO structures during hot deformation of GZ41K magnesium alloy ». Materials Characterization, vol. 131. pp. 234-243.
Compte des citations dans Scopus : 10.

[thumbnail of Jahazi M 2017 15667 Formation of precipitates in parallel arrays.pdf]
Prévisualisation
PDF
Jahazi M 2017 15667 Formation of precipitates in parallel arrays.pdf - Version acceptée
Licence d'utilisation : Creative Commons CC BY-NC-ND.

Télécharger (2MB) | Prévisualisation

Résumé

(Mg,Zn)3Gd precipitates were observed in the form of parallel arrays within a α-Mg matrix of a Mg-3.5Gd-1Zn-0.6Zr (GZ41K) alloy following isothermal holding at 450 °C for 20 min or uniaxial hot compression testing at 450 °C and at strain rates of 10− 3 s− 1 and 10− 1 s− 1. A microstructural analysis using a combination of scanning and transmission electron microscopies showed arrays of precipitates nucleated on stacking faults as a result of the LPSO structures decomposing statically after long isothermal holding times at 450 °C, which is lower than the dissolution temperature of (Mg,Zn)3Gd precipitates (520 °C), and dynamically, as a result of hot compression. The presence of precipitates on slip bands was also observed in the case of deformed specimens. The characteristics of the precipitates were investigated using differential thermal analysis, and optical and electron microscopy. The influences of the solutionizing temperature and deformation conditions on distribution, morphology and volume fraction of precipitates were quantified. The results are interpreted in terms of the influence of the strain rate in increasing the stacking fault/dislocation intersections and the decomposition of the L12 structure of stacking faults.

Type de document: Article publié dans une revue, révisé par les pairs
Professeur:
Professeur
Jahazi, Mohammad
Affiliation: Génie mécanique
Date de dépôt: 21 août 2017 21:35
Dernière modification: 13 avr. 2023 16:08
URI: https://espace2.etsmtl.ca/id/eprint/15667

Actions (Authentification requise)

Dernière vérification avant le dépôt Dernière vérification avant le dépôt
