Proportional-resonant based control strategy for grid-connected packed-E cell inverters with Lyapunov filter-based PLL

Downloads

Downloads per month over past year

Biricik, Samet, Komurcugil, Hasan, Ahmed, Hafiz, Sharifzadeh, Mohammad, Mehrasa, Majid and Al-Haddad, Kamal. 2023. « Proportional-resonant based control strategy for grid-connected packed-E cell inverters with Lyapunov filter-based PLL ». IET Generation Transmission & Distribution, vol. 17, nº 3. pp. 645-654.
Compte des citations dans Scopus : 4.

[thumbnail of Al Haddad-K-2022-25566.pdf]
Preview
PDF
Al Haddad-K-2022-25566.pdf - Published Version
Use licence: Creative Commons CC BY-NC-ND.

Download (1MB) | Preview

Abstract

A proportional-resonant (PR)-based current control strategy for grid-connected packed- E cell (PEC) inverter is presented. Unlike the existing control strategies, which are based on proportional-integral controller, developed for packed-U cell and PEC inverters, the proposed PR-based control strategy achieves zero steady-state error in the grid current. Furthermore, it eliminates the necessity of employing the control loop for regulating the dc capacitor voltages. Also, the grid current synchronization is achieved by using a Lyapunov filter-based phase locked loop (PLL). The consequence of using Lyapunov filter-based PLL is that sinusoidal synchronization signal can be extracted from the distorted grid voltage. The performances of the proposed control strategy under steady-state, load variation and non-ideal grid voltage are investigated on a laboratory-scale experimental prototype. It is reported that the control of both dc- and ac-side variables of the system are accomplished.

Item Type: Peer reviewed article published in a journal
Professor:
Professor
Al Haddad, Kamal
Affiliation: Génie électrique
Date Deposited: 06 Oct 2022 15:49
Last Modified: 02 Aug 2023 19:32
URI: https://espace2.etsmtl.ca/id/eprint/25566
