Singularity analysis of Kinova’s Link 6 Robot Arm via Grassmann Line Geometry

Asgari, Milad, Bonev, Ilian A. et Gosselin, Clément. 2024. « Singularity analysis of Kinova’s Link 6 Robot Arm via Grassmann Line Geometry ». In IEEE International Conference on Robotics and Automation (Yokohama, Japan, May 13-17, 2024) IEEE.

PDF Bonev-I-2024-28453.pdf - Version acceptée Accès restreint à : Administrateur seulement jusqu'au 18 mai 2024. Licence d'utilisation : Tous les droits réservés aux détenteurs du droit d'auteur. Télécharger (6MB) | Demande de copie

Résumé

Unlike parallel robots, for which hundreds of different architectures have been proposed, the vast majority of six-degree-of-freedom (DOF) serial robots have one of two simple architectures. In both architectures, the inverse kinematics can be solved in closed form and the singularities described by trivial geometric and algebraic conditions. These conditions can be readily obtained by analyzing the determinant of the robot’s Jacobian matrix, and provide an in-depth understanding of the robot’s singularities, which is essential for its optimal use. However, for various reasons, robot arms with unorthodox architectures are occasionally designed. Such arms do not have closed-form inverse kinematics and little insight into their singularities can be gained by analyzing the determinant of their Jacobian. One such robot arm for which the conventional singularity analysis approach fails is the new Link 6 collaborative robot by Kinova. In this paper, we study the complex singularities of Link 6 by investigating all possibilities for screw dependencies, deriving a simple equation for each case, and then describing each singularity type using Grassmann line geometry. Twelve different singularity configurations are identified and described with seven relatively simple geometric conditions. Our approach is general and can be applied to other robot arms.

Type de document:	Compte rendu de conférence
Professeur:	Professeur Bonev, Ilian
Affiliation:	Génie des systèmes
Date de dépôt:	21 mars 2024 15:19
Dernière modification:	27 mars 2024 13:57
URI:	https://espace2.etsmtl.ca/id/eprint/28453
